A15 Double Seal PPIC Cover

A15 Ductile Iron Cover & Frame, Double Seal, Locked
mhc_icon_search_dark@1x
Enlarge
Product Details
Areas which can only be used by pedestrians and pedal cyclists.
mhc_icon_class_A15@1x
A15
5 Tonnes
mhc_icon_class_A15@1x
A15
5 Tonnes

This double seal polypropylene inspection cover (PPIC) is a cast iron manhole cover with a cast iron frame. It's appropriate for foot traffic and slow moving cars.

Specification
  • mhc_icon_check@1x A15 to accept foot traffic and slow moving cars
  • mhc_icon_check@1x Cast iron cover in cast iron frame
  • mhc_icon_check@1x BS EN 124 Load Class A15
  • mhc_icon_check@1x Double seal with 2 stainless steel countersunk screws
  • mhc_icon_check@1x Lifting keys (MHC Ref. LK5200)
Available Sizes
Product code Clear Opening (mm) Over Frame (mm) Frame Depth (mm) Seal Type Loading
MHC - 5137
450 dia 660 30 double seal a15
Available Sizes
MHC - 5137
Clear Opening (mm) 450 dia
Over Frame (mm) 660
Frame Depth (mm) 30
Seal Type double seal
Loading a15
Any questions, contact our expert team on 01296 668850
